M320 Integrated Amplifier
|
| |
| |
What do you get when you combine Canary's famous 300B push-pull stereo power amplifier with a low noise tube preamplifier
in a single chassis? The answer is Canary's first 300B integrated amplifier.
The M320 is our first 300B integrated amplifier which produces 24 watts of RMS power per channel. The M320 uses four 300B tubes for the
amplifier section and four 6SN7 tubes in the preamp section. The preamp section provides 4 pairs of single-ended (RCA)
inputs to keep all your music sources connected.
Designed and manufactured entirely from the ground up by our engineering team, the M320 offers extremely high performance and value.
|
| |
|
Special Features:
Push-pull stereo triode Class A design.
Oversized hand wound power and output transformers (custom made in USA).
Exclusive machined Delrin 300B tube sockets with gold plated pin receptacles.
ALPS volume control and ELMA (Gold Contacts) selector switch.
Custom gold plated brass five-way binding posts.
Two pairs of 300B tubes pre-installed.
|
| Image Gallery
|
|
SPECIFICATIONS
|
|
Rated Power Output: |
24 Watts RMS (Class A) |
|
Input Sensitivity: |
330mV |
|
Input Impedance: |
100K Ohms |
|
Frequency Response: |
+/- 1dB from 12 Hz to 55,000 Hz |
|
Total Harmonic Distortion: |
<0.5% |
|
Signal-to-Noise Ratio: |
82 dB |
|
Damping Factor: |
10 |
|
Output Taps: |
4 ohms and 8 ohms |
|
Input: |
4 pairs single-ended (RCA) |
|
Tube Complement: |
4 x 300B
4 x 6SN7
|
|
Dimensions: |
19" W x 19.5" D x 8.25" H |
|
Net Weight: |
65 lbs |
|
Warranty: |
3 Years Parts and Labor |
|
Specifications subject to change without notice. |
|
